Kubernetes Cluster on Ubuntu 24.04: A Step-by-Step Guide

Hey everyone! So, you’re looking to get your hands dirty with Kubernetes on the latest Ubuntu 24.04, huh? That’s awesome! Setting up a Kubernetes cluster might sound like a super complex task, but trust me, guys, with a little guidance, it’s totally doable. We’re going to walk through the entire process, from prepping your servers to getting your first pods up and running. Think of this as your ultimate cheat sheet to deploying a Kubernetes cluster on Ubuntu 24.04 . We’ll break down each step so you don’t get lost in the technical jargon. Ready to dive in?

Preparing Your Ubuntu 24.04 Nodes

Alright, first things first, we need to get our machines, or nodes as we call them in Kubernetes lingo, ready. For this guide, we’ll assume you have at least two Ubuntu 24.04 servers. One will be your control plane (the brain of your cluster), and the others will be your worker nodes (where your applications will actually run). It’s super important that these machines can talk to each other over the network, so make sure your firewall isn’t blocking any necessary ports. We’ll need to do a few things on all nodes – yes, both control plane and workers. First off, update your system: sudo apt update && sudo apt upgrade -y . This is like giving your servers a fresh coat of paint and making sure they have all the latest security patches. Next, we need to disable swap. Kubernetes doesn’t play nicely with swap, so we have to turn it off. Run sudo swapoff -a and then comment out the swap line in /etc/fstab by adding a # at the beginning. You can use sudo sed -i '/ swap / s/^\(.*tag\*[^\t]*\t[^\t]*\)\( +.*\)$/#\1\2/g' /etc/fstab to do this. Crucially , you need to ensure that the br_netfilter module is loaded and that your network traffic can be bridged. This is essential for how containers communicate within the cluster. You can load the module with sudo modprobe br_netfilter and then make it persistent across reboots by creating a file: echo 'br_netfilter' | sudo tee /etc/modules-load.d/k8s.conf . To apply the bridging settings, create another file: cat <<EOF | sudo tee /etc/sysctl.d/k8s.conf net.bridge.bridge-nf-call-ip6tables = 1 net.bridge.bridge-nf-call-iptables = 1 EOF . Then, apply these settings with sudo sysctl --system . These preparatory steps are absolutely vital. Skipping any of them can lead to subtle and frustrating issues down the line, making your Kubernetes cluster installation on Ubuntu 24.04 much harder than it needs to be. So, take your time here, double-check everything, and ensure each node is perfectly prepped before moving on. It’s all about building a solid foundation, guys!

Installing Containerd Runtime

Alright, so your nodes are prepped and ready to roll. The next major step in setting up your Kubernetes cluster on Ubuntu 24.04 is installing a container runtime. Kubernetes needs something to actually run your containers, and containerd is a popular and robust choice. It’s a bit of a behind-the-scenes player, but it’s super important. First, we need to install the containerd.io package. You can do this easily with sudo apt install containerd.io -y . Once it’s installed, we need to configure it. The default configuration might not be exactly what Kubernetes expects, so we’ll generate a default config file and then tweak it. Run sudo containerd config default | sudo tee /etc/containerd/config.toml . Now, for the important part: we need to enable the systemd cgroup driver. This is how containerd communicates with the operating system’s control groups, which is crucial for resource management in Kubernetes. Open the configuration file you just created: sudo nano /etc/containerd/config.toml . Look for the [plugins."io.containerd.grpc.v1.cri".containerd.runtimes.runc.options] section. Inside this, find the line SystemdCgroup = false and change it to SystemdCgroup = true . Save the file (Ctrl+X, then Y, then Enter if you’re using nano). After saving, you need to restart the containerd service for these changes to take effect: sudo systemctl restart containerd . And to make sure it starts up every time your server boots, enable it: sudo systemctl enable containerd . Why is this SystemdCgroup setting so important, you ask? Well, Kubernetes uses cgroups to limit and isolate container resources like CPU and memory. The systemd cgroup driver ensures that containerd works seamlessly with systemd to manage these cgroups correctly. Without it, your pods might not start, or they might behave erratically. So, this step is absolutely critical for a stable Kubernetes installation on Ubuntu 24.04 . Don’t skip it, guys! It’s all about making sure your containers have a stable home to run in.

Installing Kubernetes Components (kubeadm, kubelet, kubectl)

Okay, we’ve got our nodes prepped and containerd up and running. Now it’s time to install the star players of the Kubernetes show: kubeadm , kubelet , and kubectl . kubeadm is the tool that helps us bootstrap our cluster, kubelet is the agent that runs on each node and ensures containers are running in pods, and kubectl is our command-line interface to interact with the cluster. First, let’s set up the Kubernetes package repository so apt knows where to find these components. We’ll need to install some prerequisite packages first: sudo apt update && sudo apt install -y apt-transport-https ca-certificates curl . Now, download the Google Cloud public signing key: curl -fsSL https://pkgs.k8s.io/core:/stable:/v1.29/deb/Release.key | sudo gpg --dearmor -o /etc/apt/trusted.gpg.d/kubernetes-archive-keyring.gpg . Then, add the Kubernetes repository: echo 'deb [signed-by=/etc/apt/trusted.gpg.d/kubernetes-archive-keyring.gpg] https://pkgs.k8s.io/core:/stable:/v1.29/deb/ /' | sudo tee /etc/apt/sources.list.d/kubernetes.list . After adding the repo, update your package list again: sudo apt update . Now, we can finally install the Kubernetes tools: sudo apt install -y kubelet kubeadm kubectl . It’s important to hold these packages to prevent them from being automatically updated to a potentially incompatible version later: sudo apt-mark hold kubelet kubeadm kubectl . This ensures that your cluster remains stable. After installation, we need to enable the kubelet service so it starts on boot: sudo systemctl enable kubelet . Note that kubelet will not start until kubeadm init is run, as it needs to be configured by kubeadm . So, don’t worry if you see errors about kubelet not starting yet. We’ve now got the core Kubernetes software installed on all our nodes! This is a huge milestone in your Kubernetes cluster setup on Ubuntu 24.04 . You’ve successfully brought the brain and the muscles of Kubernetes onto your servers. Pretty neat, huh?

Initializing the Control Plane Node

We’re getting so close, guys! We’ve installed all the necessary software. Now, we need to initialize the control plane node – this is where the magic of Kubernetes cluster creation really begins. Remember, you should only run this command on the node you’ve designated as your control plane. Execute the following command: sudo kubeadm init --pod-network-cidr=192.168.0.0/16 . Let’s break this down a bit. kubeadm init is the command that bootstraps a Kubernetes control plane. The --pod-network-cidr=192.168.0.0/16 flag is extremely important. It tells Kubernetes the IP address range that pods will use. This is necessary for certain network plugins (CNIs) to function correctly. Make sure this CIDR doesn’t conflict with your existing network. The output of this command is crucial. It will give you a kubeadm join command with a token and a discovery token CA certificate hash. Save this output! Seriously, copy it and paste it somewhere safe. This join command is what you’ll use later to add your worker nodes to the cluster. After kubeadm init finishes, it will also give you instructions on how to configure kubectl for your regular user. You’ll need to run these commands: mkdir -p $HOME/.kube , sudo cp -i /etc/kubernetes/admin.conf $HOME/.kube/config , sudo chown $(id -u):$(id -g) $HOME/.kube/config . Now, you can run kubectl get nodes and you should see your control plane node listed, but it will likely be in a NotReady state. That’s because we haven’t installed a network plugin yet. Don’t freak out! This is totally normal. The control plane is up, but it can’t communicate effectively without a network solution. So, while it might seem like nothing’s happening, this kubeadm init step is the fundamental building block of your Kubernetes cluster on Ubuntu 24.04 . You’ve successfully turned one of your servers into the command center!

Deploying a Pod Network Add-on (CNI)

So, your control plane node is initialized, and kubectl get nodes shows it, but it’s in a NotReady state, right? That’s because Kubernetes needs a network plugin, also known as a Container Network Interface (CNI), to allow pods to communicate with each other and with external services. Without a CNI, your pods can’t get IP addresses or route traffic correctly. For this guide, we’ll use Calico, which is a popular and powerful choice, but there are others like Flannel or Weave Net you could also use. To deploy Calico, you’ll need to apply its YAML manifest file. You can get the latest manifest from the Calico documentation, but a common command to apply it is: kubectl apply -f https://raw.githubusercontent.com/projectcalico/calico/v3.27.0/manifests/calico.yaml . This command tells Kubernetes to create all the necessary resources (like Deployments, DaemonSets, and ConfigMaps) defined in the Calico manifest. It might take a few minutes for Calico to download its container images and start up on your nodes. Once Calico is up and running, you should see its pods in the kube-system namespace. Go ahead and run kubectl get pods -n kube-system to check their status. They should all be Running . Now, if you run kubectl get nodes again, you should see your control plane node transition from NotReady to Ready ! Bingo! This is a massive step forward for your Kubernetes cluster on Ubuntu 24.04 . With a CNI installed, your cluster is now ready to start scheduling and running actual application workloads. Choosing the right CNI is important as it impacts network policies, performance, and complexity. Calico is great for its robust network policy features, but make sure you check the compatibility and requirements for the specific version you’re installing. Guys, you’re practically there! The network is the backbone of any distributed system, and Kubernetes is no exception.

Joining Worker Nodes to the Cluster

Alright, you’ve got a working control plane and a CNI installed. Now it’s time to bring your worker nodes into the fold! These are the machines that will actually run your applications. Remember that kubeadm join command you saved earlier from the kubeadm init output? It’s time to use it! SSH into each of your worker nodes and run that exact command. It will look something like this: sudo kubeadm join <control-plane-ip>:6443 --token <your-token> --discovery-token-ca-cert-hash sha256:<your-hash> . Replace <control-plane-ip> , <your-token> , and <your-hash> with the actual values you saved. If, for some reason, you lost the token or it expired (they usually last 24 hours), you can generate a new one on the control plane node with sudo kubeadm token create --print-join-command . This will output a new kubeadm join command that you can then use on your worker nodes. Once the kubeadm join command is executed on a worker node, it will connect to the control plane, get configured, and start running the kubelet agent. This process might take a minute or two. Now, head back to your control plane node (or any machine where you have kubectl configured) and run kubectl get nodes . You should now see all your worker nodes listed, and they should all be in the Ready state. Congratulations! You’ve successfully added worker nodes to your Kubernetes cluster on Ubuntu 24.04 . This is where the real power of Kubernetes comes in – you now have a pool of resources that can be used to deploy and manage your applications at scale. It’s like building your own private cloud! Make sure your worker nodes have enough resources (CPU, RAM, disk) to handle the workloads you plan to run on them. Also, ensure that the network configuration between your control plane and worker nodes is stable and allows for communication on the necessary ports. This step is all about expanding your cluster’s capacity and preparing it for actual deployment. You’ve built a solid foundation, guys!

Deploying Your First Application

We’ve done it! We’ve successfully set up a Kubernetes cluster on Ubuntu 24.04 with a control plane and worker nodes. Now, let’s have some fun and deploy our very first application. For this, we’ll deploy a simple Nginx web server. You’ll need a YAML file to define your application. Let’s create a file named nginx-app.yaml with the following content:

apiVersion: apps/v1
kind: Deployment
metadata:
  name: nginx-deployment
  labels:
    app: nginx
spec:
  replicas: 3
  selector:
    matchLabels:
      app: nginx
  template:
    metadata:
      labels:
        app: nginx
    spec:
      containers:
      - name: nginx
        image: nginx:latest
        ports:
        - containerPort: 80
---
apiVersion: v1
kind: Service
metadata:
  name: nginx-service
spec:
  selector:
    app: nginx
  ports:
    - protocol: TCP
      port: 80
      targetPort: 80
  type: LoadBalancer

This YAML defines two things: a Deployment that tells Kubernetes to run 3 replicas of the Nginx container using the nginx:latest image, and a Service of type LoadBalancer that exposes Nginx on port 80. The LoadBalancer type is a bit special; on cloud providers, it automatically provisions a cloud load balancer. In our local cluster setup, we’ll need a specific component to make this work. If you’re using a local setup like Minikube or kind, they usually have a built-in LoadBalancer solution. For a bare-metal setup like we’ve been building, you’ll typically need to install a MetalLB or similar solution. For now, let’s assume you have a way to expose LoadBalancer services (or you can change the service type to NodePort to access it via <node-ip>:30080 ). To deploy this, simply run: kubectl apply -f nginx-app.yaml . Kubernetes will now create the Deployment and the Service. You can check the status of your deployment with kubectl get deployments and your pods with kubectl get pods . You should see 3 Nginx pods running. To check the service, run kubectl get services . If you have MetalLB or a similar solution configured, you’ll see an external IP address assigned to nginx-service . If not, you might see <pending> . If you changed it to NodePort , you’ll see the NodePort allocated. You’ve officially deployed your first application on your Kubernetes cluster on Ubuntu 24.04 ! This is what it’s all about, guys – running and managing your applications in a resilient and scalable way. Pretty awesome, right?

Conclusion: Your Kubernetes Journey Begins!

And there you have it, folks! You’ve successfully navigated the exciting world of setting up a Kubernetes cluster on Ubuntu 24.04 . From preparing your nodes and installing essential components like containerd, kubelet, and kubeadm, to initializing the control plane, setting up networking with Calico, joining your worker nodes, and finally deploying your first application – you’ve accomplished a lot! This isn’t just about following a set of commands; it’s about understanding the core concepts that make Kubernetes such a powerful platform for container orchestration. You now have a solid foundation to explore more advanced Kubernetes features like persistent storage, advanced networking, scaling applications, and implementing robust security policies. Remember, the Kubernetes ecosystem is vast and constantly evolving, so continuous learning is key. Don’t be afraid to experiment, break things (in a safe test environment, of course!), and learn from them. This journey into Kubernetes is just beginning, and with your newfound skills on Ubuntu 24.04, you’re well-equipped to tackle complex containerized deployments. Keep building, keep learning, and welcome to the awesome world of Kubernetes, guys!
